Description
Wireless Features:
| Wireless Standards | IEEE802.11ac/a/b/g/n |
| Frequency | 2.4GHz & 5.8GHz |
| Signal Rate | 2.4GHz
11n:Up to 150Mbps(dynamic) 11g:Up to 54Mbps(dynamic) 11b:Up to 11Mbps(dynamic)
5.8GHz 11ac:Up to 433Mbps(dynamic) 11a:Up to 54Mbps(dynamic)
|
| Reception Sensitivity | 11a 6Mbps:-88dBm
11a 54Mbps:-71dBm 11ac HT20:-65dBm 11ac HT40:-60dBm 11ac HT80:-56dBm 11b 11Mbps:-90dBm 11g 54Mbps:-73dBm 11n HT20:-71dBm 11n HT40:-68dBm |
| Transmit Power | <20dBm(EIRP) |
| Wireless Modes | Ad-Hoc/Infrastructure |
| Wireless Security | Support 64/128 bit WEP,WPA-PSK/WPA2-PSK, |
| System Requirement | Windows 8(32/64bits),Windows 7(32/64bits),Windows XP(32/64bits) |
| Environment | Operating Temperature:0℃~40℃(32℉~104℉)
Storage Temperature:-40℃~70℃(-40℉~158℉) Operating Humidity:10%~90% non-condensing Storage Humidity:5%~90% non-condensing |
BT Feature:
| BT Version | BT 4.1/BT 4.2 |
| Antenna Reference | Small gain peak antenna for 0~2dBi |
| Working Frequency | 2.4G:2.4000GHz~2.4835GHz |
| Channel | 0~78 channel |
| Modulation | 8DPSK,n/4 DQPSK,GFSK |
| Transmission Range | Within 10 meters |
| Transmission Speed | 1Mbps basic rate
2.3Mbps post enhancement rate |
| Maximum Input Level | GFSK(1Mbps):-20dBm
n/4-DQPSK(2Mbps) 8DPSK(3Mbps) |
| Environment Requirement | Working Temperature:-10℃~50℃
Storage Temperature:-20℃~50℃
|
| Support system | Win7/Win8/Win10 |
