Build a custom gaming PC that perfectly captures your style with the Lian Li Vector V100 Mid-Tower PC Case. This case boasts excellent compatibility with the latest gaming hardware including back connector ATX motherboards, full-sized GPUs, and PSUs up to 220mm long. Plus, you’ll be able to maintain your hardware at optimal temperatures easily, thanks to AIO support and mounts for up to nine 120mm fans. With its two tempered glass panels on the side and front, plus an integrated ARGB light strip on the PSU shroud, the Vector V100 is ideal for building a showcase PC. Additionally, it offers a unique figure platform at the front of the case, allowing you to display your favourite models.
Lian Li Vector V100 Mid-Tower Case at a Glance:
- Mid-tower case measuring 446mm x 235.5mm x 484.65mm (DxWxH)
- Supports modern gaming hardware including rear connector ATX motherboards
- GPU clearance of up to 415mm
- Compatible with radiators up to 360mm long
- Install up to nine 120mm fans
- Innovative customisation options, including a figure stand
Entry Level Gaming Case
The Lian Li Vector V100 is equipped with an extensive range of features that make it ideal for first time builders on a budget. The spacious interior of the V100 offers ample room for the latest gaming hardware, with a motherboard tray that can support E-ATX motherboards up to 246mm or rear connector ATX motherboards. Additionally, with a CPU cooler clearance of 180.5mm and space for GPUs up to 415mm long, you can easily build a powerhouse gaming PC with the Vector V100.
Underneath the main chamber of this case is a large PSU cavity with a unique design. Within this compartment, there is space to install an ATX power supply up to 220mm long, with room for easy cable management. Instead of stretching along the full length of the chassis, the PSU chamber shroud angles down to create a stylish aesthetic.
Personalise Your PC
Show off your unique style and gaming hardware in the Lian Li Vector V100. Featuring two crystal-clear tempered glass side and front panels with no support pillar, you’ll have a panoramic view inside your case. To ensure your PC looks super clean, the Vector V100 has excellent cable management options, with ample space behind the motherboard tray and in the PSU chamber to conceal excess wires.
Along the top of the PSU shroud is an ARGB light strip. This features 26 vibrant LEDs that can be illuminated using a range of colours and effects. Additionally, there is a figure panel at the front of the chamber. Simply remove the pre-installed airflow cover, and you can proudly display your favourite model.
Powerful Cooling
A PC built with the Lian Li Vector V100 Mid-Tower PC Case will feature excellent thermal performance, thanks to its extensive support for cooling hardware. The Vector V100 boasts up to nine mounting points for fans. The side of the case can support three 120mm fans, whilst two more can be attached to the top of the PSU shroud. The rear can facilitate an additional 120mm or 140mm fan. Meanwhile, the top offers mounts for either three 120mm or two 140mm fans. The Vector V100 also offers support for up to 360mm radiators. These can be installed at the top of the case, in either a push or pull configuration.
Fan Header | |
Fan Controller / Fan Hub | No |
Lighting | |
Lighting / RGB | Yes |
Back Connect | |
Back Connect | Yes |
Case Features | |
I/O position | Side |
Side panel | with window |
Vertical GPU Mount | No |
Adjustable Vertical GPU Bracket | No |
Front door | No |
Cable Management | Yes |
Filters Included | Yes |
Filter Position | Bottom |
Noise dampening | No |
Mainboard slide / tray | No |
Transport System | No |
Colour | |
Primary Colour | Black |
Fan Main Colour (Frame) | Black |
Motherboard Support | |
Compatible Motherboard Formats | ATX, Micro-ATX, Mini-ITX |
Max. Motherboard Format | ATX |
Power Supply | |
PSU included | No |
PSU Format | ATX |
Power Supply Position | rear bottom |
Product Series | |
Product Series/Family | Vector V100 |
Display | |
Display Included | No |
Dimensions | |
Length / Depth | 446 mm |
Width | 235.5 mm |
Height | 484.65 mm |
Additional Contents | |
Included fans | 4x 120 mm |
Internal Dimensions | |
Max. CPU Cooler Height | 178 mm |
Max. GPU Length | 420 mm |
Max. PSU Length / Depth | 220 mm |
Materials | |
Materials | Steel, Tempered Glass |
Mounting | |
Internal Monitor Mount | No |
Case VESA Mountable | No |
Features | |
Housing Feedthrough | No |
Compliance | |
Compliance Documents | Lian Li Vector V100 Compliance and Safety |
Expansion Slots | |
Expansion slots / PCI slots | 7 |
Drive Bays | |
Max. 2.5 Inch Drives | 1 |
Max. 3.5 Inch Drives | 1 |
Max. 5.25 Inch Drives | 0 |
Hot swap drive bays | No |
Fan Support | |
Max. Number of Fans | 9 |
120 mm fans | 9 |
140 mm fans | 6 |
Case | |
Case Type | Mid Tower |
Radiator Support | |
Max. Radiator Compatibility | 1x Triple (360 mm) |
External Ports | |
USB 3.1 (external) Type C | 1 |
USB 3.0 (external) Type A | 2 |
Audio outputs & inputs | 1x output / input comb. (3.5 mm jack, 4-pin, TRRS) |
Card reader | No |
Cable Specifications | |
Riser Cable Included | No |
Weight | 10 kg |
---|
