Key Features
– Addressable RGB LED lighting
– Economic solution for the perfect performance
– Nine blade design optimised for air flow
– 3-Pin AURA connector

Fan Dimensions
120mm

LED Type
Addressable RGB

Frame Colour
Black

Blade Colour
White

Number of Blades
9

Number of LEDs
8

Bearing Type
Hydraulic Bearing

Max Fan Speed
1200RPM +/-10%

Max Air Flow
39.6CFM

Max Static Air Pressure
0.97mm-H2O

Noise Level
=25.3DBA

Cable Length
550mm

Connections
3-Pin Fan
3-Pin 5V AURA

Rated Voltage
DC 12V (Fan)
DC 5V (LED)

Rated Current
0.25A (Fan)
0.3A (LED)

Rated Input Power
3W (Fan)
1.5W (LED)

Test Voltage
DC 12V (Fan)
DC 5V (LED)

Start Voltage
=6V

Operating Voltage
5V – 13.2V

MTBF
30,000 hours

What’s In The Box
Fan
4 x Fan Screws

Product Dimensions ( W x H x D )
120 x 120 x 25mm

Packaging Dimensions ( W x H x D )
140 x 123 x 27mm

Weight
Net: 0.16 KGs
Gross: 0.2 KGs
