Intel® for 8^th Generation Core^™ Processors
Supports Intel® Turbo Boost Technology 2.0
* Refer to www.asus.com for CPU support list

Build in Intel® B360

Intel® B360 Chipset
4 x DIMM, Max. 64GB, DDR4 2666/2400/2133 MHz Non-ECC, Un-buffered Memory
Dual Channel Memory Architecture
Supports Intel® Extreme Memory Profile (XMP)
* Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
** DDR4 2666MHz and higher memory modules will run at max. 2666MHz on Intel® 8th Gen. 6-core or higher processors.

Integrated Graphics Processor- Intel® HD Graphics support
Multi-VGA output support : HDMI/DVI-D ports
– Supports HDMI with max. resolution 4096 x 2160 @ 30 Hz
– Supports DVI-D with max. resolution 1920 x 1200 @ 60 Hz
Maximum shared memory of 1024 MB (for iGPU exclusively)

Supports AMD 2-Way CrossFireX Technology

1 x PCIe 3.0 x16
1 x PCIe 3.0 x16 (max at x4 mode)
2 x PCIe 3.0/2.0 x1

Intel® B360 Chipset :
1 x M.2 Socket 3, with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode)*
1 x M.2 Socket 3, with M Key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 2 mode)
6 x SATA 6Gb/s port(s)
Intel® Optane™ Memory Ready *

Intel® I219V
Anti-surge LANGuard
ROG GameFirst IV

ROG SupremeFX 8-Channel High Definition Audio CODEC S1220A
– Dual OP Amplifiers
– Impedance sense for front and rear headphone outputs
– Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking
– High quality 120 dB (Line-out at rear) 113 dB SNR recording input
Audio Feature :
– SupremeFX Shielding™ Technology
– Optical S/PDIF out port(s) at back panel
– LED-lit Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference, with a gorgeous illuminated trace path
– Premium Japanese-made audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity
– Sonic Radar III
– Sonic Studio III + Sonic Studio Link

Intel® B360 Chipset :
2 x USB 3.1 Gen 2 port(s)
Intel® B360 Chipset :
4 x USB 3.1 Gen 1 port(s)
Intel® B360 Chipset :
6 x USB 2.0 port(s)

ROG RAMCache II
ROG CloneDrive
Pre-mounted I/O Shield
Overwolf
GameFirst IV

Gamer’s Guardian:
– ESD Guards on LAN, Audio, KBMS and USB3.1/3.0/2.0 ports
– DRAM Overcurrent Protection
– 10K Black Metallic Capacitors
– Stainless Steel Back I/O
– Highly Durable Components
– DIGI+ VRM
– SafeSlot
AURA :
– Aura Lighting Control
– Aura RGB Strip Headers
ASUS Exclusive Features :
– GPU Boost
– AI Suite 3
– ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface
ASUS Quiet Thermal Solution :
– ASUS Fan Xpert 4 Core
ASUS EZ DIY :
– ASUS CrashFree BIOS 3
– ASUS EZ Flash 3
– ASUS MyLogo
ASUS Q-Design :
– ASUS Q-Slot
– ASUS Q-DIMM

1 x PS/2 keyboard/mouse combo port(s)
1 x DVI
1 x HDMI
2 x USB 3.1 Gen 2
1 x Optical S/PDIF out
5 x Gold-plated audio jacks
2 x USB 3.1 Gen 1 (blue)
2 x USB 3.1 Gen 2 (red)Type-A
Anti-surge LAN (RJ45) port

1 x AAFP connector
1 x Aura RGB Strip Header
1 x USB 3.1 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s)
2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
1 x M.2 Socket 2 with M Key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 X2 mode)
1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (PCIE 3.0 x 4 mode)
1 x TPM header
1 x COM port(s) connector(s)
6 x SATA 6Gb/s connector(s)
1 x CPU Fan connector(s)
2 x Chassis Fan connector(s)
1 x AIO_PUMP connector
1 x 24-pin EATX Power connector(s)
1 x 8-pin EATX 12V Power connectors
1 x Front panel connector(s)
1 x Clear CMOS jumper(s)

User’s manual
2 x SATA 6Gb/s cable(s)
1 x M.2 Screw Package
1 x Supporting DVD
1 x Strix door hanger
1 x CABLE TIE BLACK
1 x ROG Strix stickers

1 x 128 Mb Flash ROM, UEFI AMI BIOS, PnP, WfM2.0, SM BIOS 3.0, ACPI
6.0, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F6 Qfan
Control, F3 My Favorites, Last Modified log, F12 PrintScreen and ASUS
DRAM SPD (Serial Presence Detect) memory information, ASUS Secure
Erase, ASUS User Profile, F4 AURA ON/OFF, F9 Search

WOL, WOR, PXE

Windows® 10 64-bit

mATX Form Factor
9.6 inch x 9.6 inch ( 24.4 cm x 24.4 cm )
