Intel Specification
ATX12V
PFC Type
Active PFC
Dimensions
16 x 15 x 8.6 Centimeter
Efficiency
80Plus Gold
MTBF
>120,000 hrs @ 25°C
Protection Features
OPP/OVP/UVP/SCP/OCP/OTP
Hazardous Materials
ROHS
AC Input Range
100-240Vac
RGB Connector
NO
Fan Size
135 mm
DC Output Voltage
+3.3V +5V +12V -12V +5Vsb
Maximum Load
20A 20A 70A 0.3A 3A
Combined Load
100W 100W 840W 3.6W 15W
Total Output
850W
Cable Connectors
MB 24/20-pin x 1
CPU 4+4-pin x 2
PCI-E 6+2-pin x 6
SATA x 8
PERIPHERAL x 6
CPU 4+4-pin x 2
PCI-E 6+2-pin x 6
SATA x 8
PERIPHERAL x 6
Package Contents
Power Cord x 1
Motherboard Power Cable x 1 (610mm)
CPU Cable x2 (1000mm)
PCIE 1-to-2 Cable x3 (675+75mm)
SATA 1-to-4 Cable x1 (410+150+150+150mm)
SATA 1-to-4 Cable x1 (450+120+120+120mm)
Peripheral 1-to-3 Cable x2 (450+120+120mm)
ROG badge x 2
ROG logo magnet x 1
ROG label x 3
*MB/ CPU/ PCI-E cables come with embedded capacitors in the middle.
Motherboard Power Cable x 1 (610mm)
CPU Cable x2 (1000mm)
PCIE 1-to-2 Cable x3 (675+75mm)
SATA 1-to-4 Cable x1 (410+150+150+150mm)
SATA 1-to-4 Cable x1 (450+120+120+120mm)
Peripheral 1-to-3 Cable x2 (450+120+120mm)
ROG badge x 2
ROG logo magnet x 1
ROG label x 3
*MB/ CPU/ PCI-E cables come with embedded capacitors in the middle.
Weight
Single Card (KG) 1.825
Product Weight (with packing) (KG) 3.48
Product Weight (with packing) (KG) 3.48
Cybenetics Noise Level Certification
NA
0dB Technology
Supported. The fan shuts off entirely when the PSU is under certain load
