Description
General Specifications
Performance
Fan Speed:200—1800 rpm PWM Controlled (0 rpm below 5 % PWM)
Airflow:56.30 cfm | 95.70 m³/h
Static Pressure:2.20 mmH2O
Noise Level:0.3 Sone
Operating Ambient Temperature:0—40 °C
Warranty:6 years
Fan
Fan Frame:Standard
Control Type:PWM PST
Connector:4-Pin Connector + 4-Pin Socket
Fan Bearing:Fluid Dynamic Bearing
Electric Characteristics
Typical Voltage:12 V DC
Starting Voltage:3.9 V
Current | Voltage:0.1 A | 12 V DC
Cable Length:400 mm
Size & Weight
Length:120 mm
Width:120 mm
Height:25 mm
Weight:145 g
