Description
Key Features
– Addressable RGB LED lighting
– Economic solution for the perfect performance
– Nine blade design optimised for air flow
– 3-Pin AURA connector
Fan Dimensions
120mm
LED Type
Addressable RGB
Frame Colour
Black
Blade Colour
White
Number of Blades
9
Number of LEDs
8
Bearing Type
Hydraulic Bearing
Max Fan Speed
1200RPM +/-10%
Max Air Flow
39.6CFM
Max Static Air Pressure
0.97mm-H2O
Noise Level
=25.3DBA
Cable Length
550mm
Connections
3-Pin Fan
3-Pin 5V AURA
Rated Voltage
DC 12V (Fan)
DC 5V (LED)
Rated Current
0.25A (Fan)
0.3A (LED)
Rated Input Power
3W (Fan)
1.5W (LED)
Test Voltage
DC 12V (Fan)
DC 5V (LED)
Start Voltage
=6V
Operating Voltage
5V – 13.2V
MTBF
30,000 hours
What’s In The Box
Fan
4 x Fan Screws
Product Dimensions ( W x H x D )
120 x 120 x 25mm
Packaging Dimensions ( W x H x D )
140 x 123 x 27mm
Weight
Net: 0.16 KGs
Gross: 0.2 KGs
