Description
Prime Performance
With 80+ Gold certification, dual ball bearing fans, and an 8-year warranty, the ASUS Prime series PSU brings efficient and durable power delivery to high-performance workstations, all-round PCs, and gaming rigs.
Dual Ball Fan Bearings
Exemplary cooling is provided by a 135mm fan spinning on a dual ball bearing setup that will last up to twice as long as a sleeve bearing design.
80 Plus Gold Certification
The ASUS Prime 750W Gold PSU features efficient, low-ESR capacitors to ensure efficient operation — affording it 80 PLUS® Gold status. This means it delivers up to 92% efficiency, resulting in less heat, reduced fan noise, and increased reliability.
ATX 3.0 Compatible
The latest power specification updates have landed. ATX 3.0 ushers in tighter voltage and current regulation guidelines for next-gen hardware – and ASUS Prime 750W Gold steps ahead of the curve by being fully compliant. A 16-pin PCIe cable that is compatible with PCIe Gen 5.0 graphics cards is bundled with the PSU, bringing large-scale capabilities.
Choose Your Style
Two sides of the housing are painted white, and two sides are painted black, allowing you to orient the PSU to match your preferred build theme.
Specification
Form Factor – ATX
Series – Asus Prime Gold
Wattage – 750 W
Modular – Fully Modular
Compatibility – ATX 3.0 / PCIe 5.0
Connectors:
1 x MB 24/20-pin
2 x CPU 4+4-pin
1 x PCIe 16-pin (both PSU & connector side)
3 x PCIe 8-pin
5 x SATA
3 x Peripheral
2 x CPU 4+4-pin
1 x PCIe 16-pin (both PSU & connector side)
3 x PCIe 8-pin
5 x SATA
3 x Peripheral
AC Input – 100-240Vac
PFC – Active PFC
Fan Type – 135mm Double Ball-Bearing Fan
Fan Bearing – Ball Bearing
80+ Certification – 80+ Gold
Efficiency – Up to 92%
MTBF – 120,000 hrs @ 25°C
Protection – OPP / OVP / UVP / SCP / OCP / OTP
Weight/Dimensions – 1.466 kg / 150 x 150 x 86 mm
Package Weight – 4.2500 kg
Warranty – 8 Years
